ARCHITECTURAL + STRUCTURAL PLANS $4,125
PREAPPROVED ADU
THE 16th
Named after the street where the prototype lives, this 476 square feet ADU has 1 bedroom, 1 bathroom, a kitchen, laundry room and walk-in closet. It's Craftsman style matches many homes in San Jose or neighboring communities and can be modified by changing materials to match almost any existing house.
Preapproved in San Jose, Fremont and Cupertino.
Requires a 19' x 27' building pad.
Architectural and Structural Plans Include
Architectural
-
Floor Plan
-
Roof Plan
-
Exterior Elevations
-
Window and Door Schedules
-
Details
-
Cross Sections
-
Fire Rating
-
Recommended Site Locations
-
Lighting and Electrical Plan
-
Specific Code Notes
-
Title 24 Energy Calculations
-
Solar Panels Sizing
-
Mechanical System
Structural
-
Foundation Plan
-
Framing Plan
-
Shear Walls
-
Roof Framing Plan
-
Structural Construction Details
-
Special Inspections Notes
Additional Add Ons
Site Planning
$4400.00
A site plan with the specific location for the ADU and showing all existing utility services, parking, and location of the primary residence. It's recommended that we are provided with a survey done by a civil engineer. A site visit to evaluate and understand property, topography, tree locations and other site constraints for Santa Clara and San Mateo Counties primarily. We will discuss options for a site visit with you if your property is located in other counties.
Interior Architecture
$2750.00
Interior architecture includes the selections of fixtures, appliances, tile, cabinet and counter finishes for the kitchen, selections for the bathroom, and the flooring, specialty lighting, trim and paint for the inside of the ADU provided in drawings and text on pages that fit into the construction drawings set.
